Table 2-1 Factory Values
Parameter
Factory Value
FREQ
Frequency
DSG830: 3 GHz
DSG815: 1.5 GHz
LF
Switch
Off
Output Waveform
Sine
Output Level
500 mV
Output Frequency
1 kHz
Square Output Level
500 mV
Square Output
Frequency
1 kHz
LEVEL
Level
-110 dBm
Flatness Switch
Off
Amplitude Unit
dBm
SWEEP
Sweep Manner
Off
Sweep Type
Step
Sweep Mode
Cont
Start Frequency of Step
Sweep
100 MHz
Stop Frequency of Step
Sweep
1 GHz
Start Level of Step
Sweep
-10 dBm
Stop Level of Step
Sweep
-20 dBm
Number of Sweep
Points
91
Dwell Time
100 ms
Sweep Space
Lin
Sweep Shape
Ramp
Trigger Mode of the
Sweep Period
Auto
Trigger Mode of Each
Sweep Point
Auto
External Trigger Polarity
Pos
Sweep Direction
Fwd
