RIGOL Chapter 2 Command System
2-18 MSO1000Z/DS1000Z Programming Guide
:CURSor:MANual:SOURce
Syntax
:CURSor:MANual:SOURce <source>
:CURSor:MANual:SOURce?
Description
Set or query the channel source of the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<source>
Discrete
{CHANnel1|CHANnel2|CHANnel3|
CHANnel4|MATH|LA}
CHANnel1
Explanation
 Only the channel that is enabled currently can be selected.
 When LA is selected, the cursor type cannot be set to Y (:CURSor:MANual:TYPE).
Return
Format
The query returns CHAN1, CHAN2, CHAN3, CHAN4, MATH, or LA.
Example
:CURSor:MANual:SOURce CHANnel2 /*Set the channel source to CH2*/
:CURSor:MANual:SOURce? /*The query returns CHAN2*/
:CURSor:MANual:TUNit
Syntax
:CURSor:MANual:TUNit <unit>
:CURSor:MANual:TUNit?
Description
Set or query the horizontal unit in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<unit>
Discrete
{S|HZ|DEGRee|PERCent}
S
Explanation
 S: AX, BX, and BX-AX in the measurement results are in "s" and 1/|dX| is in "Hz".
 HZ: AX, BX, and BX-AX in the measurement results are in "Hz" and 1/|dX| is in "s".
 DEGRee: AX, BX, and BX-AX are in "degree".
 PERCent: AX, BX, and BX-AX are expressed in percentage.
Return
Format
The query returns S, HZ, DEGR, or PERC.
Example
:CURSor:MANual:TUNit DEGRee /*Set the horizontal unit to "degree"*/
:CURSor:MANual:TUNit? /*The query returns DEGR*/
