Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-19
:CURSor:MANual:VUNit
Syntax
:CURSor:MANual:VUNit <unit>
:CURSor:MANual:VUNit?
Description
Set or query the vertical unit in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<unit>
Discrete
{PERCent|SOURce}
SOURce
Explanation
 PERCent: AY, BY, and BY-AY in the measurement results are expressed in percentage.
 SOURce: the units of AY, BY, and BY-AY in the measurement results will be
automatically set to the unit of the current source.
Return
Format
The query returns PERC or SOUR.
Example
:CURSor:MANual:VUNit PERCent /*Set the system to express AY, BY, and BY-AY in the
measurement results in percentage*/
:CURSor:MANual:VUNit? /*The query returns PERC*/
Related
Command
:CHANnel<n>:UNITs
:CURSor:MANual:AX
Syntax
:CURSor:MANual:AX <x>
:CURSor:MANual:AX?
Description
Set or query the horizontal position of cursor A in the manual cursor measurement mode.
Parameter
Name
Type
Range
Default
<x>
Integer
5 to 594
100
Explanation
The horizontal and vertical positions of the cursor are defined by the pixel coordinate of
the screen. The pixel coordinate of the screen ranges from (0,0) to (600,400). Wherein,
(0,0) is located at the left top corner of the screen and (600,400) is located at the right
bottom corner of the screen. The horizontal pixel range is from 0 to 600 and the vertical
pixel range is from 0 to 400.
Return
Format
The query returns an integer between 5 and 594.
Example
:CURSor:MANual:AX 200 /*Set the horizontal position of cursor A to 200*/
:CURSor:MANual:AX? /*The query returns 200*/
