Rinnai Blaze 21 - Rinnai Heater Overview; General Design Layout

ABOUT YOUR PORTABLE CONVECTOR HEATER
GENERAL DESIGN LAYOUT
Control panel
ON / OFF button
Stops and operates the heater.
Remote control receiver window
Louvre, warm air discharge
Carry handle(s)
Gas inlet connection
Filter 1
Filter 2
Thermistor
240v power cord
Power cord tidy
