Rinnai Control-R - 2 Lets Get Started; Step 1: Install Module; Step 2: Connect Module to Water Heater and Configure Settings

Recirculaon with On-Demand Accessories User Guide
12
Not sure if you have a SENSEI™ or non-SENSEI™ water heater? Refer to
the Tankless Water Heaters with Circ-Logic secon for a complete list
of models.
Place magnec back
panel of module to side of
water heater.
(Indoor Water Heaters Only)
Refer to Appendix A for
detailed installaon
instrucons.
You will need:
• On-Demand Accessory and Baeries (supplied with purchase)
• Control-R™ Wi-Fi Module
• Phillips Head Screwdriver (eld-supplied)
Addional Items Required for SENSEI™ Water Heaters:
• Water Heater Controller Cable (included in water heater packaging)
• Two Wire Nuts (or other approved wire connectors) (eld-supplied)
• Wire Cuer/Stripper (oponal) (eld-supplied)
IMPORTANT
Before you begin, make sure recirculaon sengs are disabled
(turned o) on the tankless water heater. For instrucons, see
Appendix B → Recirculaon Sengs secon.
