Rinnai FC824 User Manual

Fan Convector Manual 35
NO PARTNAME PARTNUMBER QTY.
001 FRONT PANEL 909000001 1
003 LOUVER ASSEMBLY 909000002 1
005 REAR PANEL 909000035 1
007 THERMOCOUPLE TEST PORT 909000003 1
008 TOP PLATE ASSEMBLY 905000013 1
010 INDICATER PANEL 909000037 1
016 BASE 909000004 1
018 HANDLE 909000005 1
020 CORD HOLDER 909000006 2
021 AIR FILTER‐A 908000001 1
023 AIR FILTER‐B 908000002 1
025 RESIN SCREW RC‐513‐20 1
026 THERMISTOR COVER 909000007 1
100 SECONDARY AIR COVER ASSEMBLY 909000008 1
101 BURNER ASSEMBLY 906000001 1
102 GAS CONTROL ASSEMBLY 906000021 1
103 O RING M10B‐1‐8 2
104 CONNECTION PIPE 906000022 1
105 CONNECTION PIPE BRACKET RC‐152‐220X03 2
106 INJECTOR (Natural Gas) 906000002 1
106 INJECTOR (Propane Gas) 906000003 1
107 PILOT INJECTOR (Natural Gas) 906000004 1
107 PILOT INJECTOR (Propane Gas) 906000005 1
108 O RING 909000009 2
109 FILTER 908000003 1
112 BLIND SCREW AU39‐965X01 1
115 GAS INLET 431F‐1110‐2 1
116 FILTER 908000008 1
117 PACKING C311‐7 1
118 INJECTOR HOLDER 906000006 1
119 CONNECTION PIPE FIXING PLATE 909000010 1
120 INJECTOR FIXING PLATE 909000011 1
121 DAMPER (Natural Gas) 906000007 1
121 DAMPER (Propane Gas) 906000008 1
122 COMBUSTION CHAMBER ASSEMBLY 906000009 1
123 ELECTRODE 905000001 1
124 ELECTRODE BRACKET RC‐512‐51 1
125 SILICON TUBE RC‐223‐84‐BX03 1
126 COMBUSTION CHAMBER COVER 906000010 1
129 UPPER SEPARATION BRACKET 909000012 1
130 CABLE CLIP CP‐90125‐4 2
131 LID 909000013 1
132 HEAT SHIELD 906000011 1
133 SEPARATION BOARD 909000014 1
134 PARTITION BOARD 909000015 1
