Rinnai FC824 User Manual

36 Fan Convector Manual
NO PARTNAME PARTNUMBER QTY.
135 BURNER LID 906000012 1
136 THERMOCOUPLE BRACKET‐A 909000016 1
137 THERMOCOUPLE FIXER RC‐210‐89X01 2
138 THERMOCOUPLE BRACKET‐B 909000017 1
139 CASING ASSEMBLY 909000018 1
140 CONVECTION FAN 908000004 1
141 BEARING BRACKET RC‐504‐32 1
142 BEARING RC‐223‐74 1
143 MOTOR BRACKET‐A 909000019 1
144 MOTOR BRACKET‐B 909000020 1
148 IGNITER BRACKET 909000021 1
157 LOUVER ASSEMBLY BRACKET RC‐291‐28 1
159 THROAT COVER 909000022 1
162 EDGE HOLDER CP‐90207 1
163 GUARD PLATE 909000023 1
700 P.C.B. ASSEMBLY 905000006 1
702 THERMOCOUPLE TOTAL ASSEMBLY RC‐511‐166‐3 2
703 THERMAL FUSEHARNESS 905000002 1
704 POWER SUPPLY CORD 905000007 1
705 THERMISTOR RC‐361‐140‐4 1
709 THERMOCOUPLE CHECK LEAD WIRE 905000003 1
710 CONVECTION FAN MOTOR 908000005 1
713 CONVECTION FAN MOTOR ASSEMBLY 908000006 1
715 IGNITER 905000009 1
716 EARTH HARNESS 905000004 1
717 MODULATING VALVE HARNESS 905000005 1
719 IGNITER HARNESS 905000010 1
802 WARNING PLATE RC‐506‐1042 1
888 OWNER'S MANUAL 900000001 1
901 ANCHOR AU102‐902 2
902 SCREW 909000024 2
903 MANUAL VALVE ASSEMBLY BRR37‐244 1
904 FLOOR FIXING PLATE RC‐592‐1035 2
PartsListforFC510(connued)

Rinnai FC824 Specifications
