Rinnai 11 RDV 600_700ER IM
ELECTRICAL SUPPLY
GPO (General Purpose Outlet)
Where a power point is used it MUST be 230 V, rated at 10A and MUST be
earthed. This power point MUST NOT be located above the heater. Alternatively
the appliance can be direct wired if the power supply is to be concealed.
The heater engine is tted with a 1.5 m power cord and three pin plug (7a) which
exits the appliance from the rear panel at the lower left.
Direct Wired Installations
Alternatively the appliance can be direct wired if so required.
A qualied electrician will need to be consulted where a direct
wired installation is required.
Any such installation MUST comply with the requirements
of AS/NZS 5601, AS/NZS 3000 and any other relevant local
regulations.
7a
SUPPLY CONNECTIONS
