Rinnai RDV700ER Installation Manual

Rinnai 14 RDV 600_700ER IM
BASIC FLUE KITS
RDVFF Masonry chimney kit - RDV Flexi Flue 650/750.
2 x exi pipes, 4x pipe clips and high wind terminal cap.
Rinnai Order Code: RDVFF
WARNING
RDVFF is NOT suitable for combustible material constructions.
RDVFA False Fire place base kit - RDV Flue Adaptor 650/750.
2 x exi pipes, 4x pipe clips, co-linear to coaxial adaptor and coaxial mounting plate (E).
Rinnai Order Code: RDVFA
IMPORTANT
A horizontal masonry installation will utilise the RDVFA as the basis for the installation.
A horizontal masonry installation MUST use a horizontal masonry terminal mount (11) to a󰀩x
both the co-linear adaptor (supplied with RDVFA) and the horizontal terminal (10) (supplied as
an additional ue component) to the exterior wall.
ADDITIONAL FLUE COMPONENTS
(1)
Pipe length 48 inch - (1200mm), Rinnai Order Code: - RDV902
(2)
Pipe length 36 inch - (900mm), Rinnai Order Code: - RDV903
(3)
Pipe length 24 inch - (600mm), Rinnai Order Code: - RDV904
(4)
Pipe length 12 inch - (300mm), Rinnai Order Code: - RDV906
(5)
Pipe length 9 inch - (230mm), Rinnai Order Code: - RDV907
(6)
Adjustable Pipe Length 11 - 14 inch - (275 - 375mm), Rinnai Order Code: - RDV911 7
(7)
45° Elbow, Rinnai Order Code: - RDV945G
(8)
90° Elbow, Rinnai Order Code: - RDV990G
(9)
High Wind Terminal Cap (Vertical Cowl) - Rinnai Order Code: - RDV991
NOTE
RDV991 may ONLY be used in conjunction with RDVFA (RDV Flue Adaptor). NOT suitable for
use with RDVFF (RDV Flexi Flue).
(10)
Square Horizontal Terminal Cap (Horizontal Terminal), (600mm), Rinnai Order Code: - RDV984
(11)
Horizontal Masonry Terminal Mount Kit - Rinnai Order Code: RDVHFS. This kit exists of three
components:
(11a) = Mount Cowl Masonry
(11b) = Plate Chimney Mount and
(11c) = Template. (This template is used for the installation only, discard this template after use).
FLUEING
