FlueInstallaƟon(indoormodelsonly)
VerƟcalTerminaƟon
(condensatecollectormustbeusedinallinstallaƟons)
3in(75mm)
minimum
3in(75mm)
minimum
HorizontalTerminaƟonusingthe
CondensateCollector
3in(75mm)
minimum
Condensate
Trap
ToadjustthecondensatecollectorposiƟonorto
replacethefemaleventtopwithamaleventtop: 
1. Loosenthe4screwsattherearbracket
2. Slidethebracketawayfromthefemaleventtop.
3. Removethe4 screwsaƩachingthefemaleventtop
tothe
waterheater.
4. LiŌupthefemaleventtopandreposiƟonasdesired
(orreplacewithamaleventtop).
5. Installthe4screwsattheventtopand Ɵghtenthe4
screwsatthebracket.
Securethefirstventcomponenttothewaterheater
withoneselfͲtappingscrewattheholelocatedabove
thecondensatecollector.
Bracket
CondensateCollector
SecuringScrew
HorizontalTerminaƟonwithoutusingtheCondensateCollector
MaximumHeight*
5feet(1.52m)
Regionsofcoldclimatewillcreatemore
condensateintheventsystem.The
condensatecollectorshouldbeusedin
coldclimates.
Ifmorethanoneelbowisusedinthe
verƟcalsecƟonthecondensatecollector
mustbeused.
*Thecondensatecollectormustbeusedin
horizontalterminaƟonsifaverƟcalrisein
theventsystemexceeds5Ō.
Ifthecondensatecollector isnot used,thedrainpipe
mustbecappedtopreventexha ustgase sand
condensatefromenteringthebuilding.Thecapis
suppliedontheappliance.
WARNING
InstallthevenƟngterminaƟonaccordingtothediagramsandinstrucƟonsbelow.
