Rinnai RL94e REU-VC2837WD-US User Manual

 VCSeriesManual 19
ConnectWaterHeatertoWaterSupply
WaterconnecƟonstothetanklesswaterheater
shouldfollowallstateandlocalplumbingcodes.
IfthisisastandardinstallaƟon,refertothePiping
DiagramforBasicInstallaƟon.
1. Plumbwatersupplytothetanklesswaterheater
onthe3/4”MNPTconnecƟonattheboƩom
of
theunitmarked“WaterInlet”,whichisthecold
watersupply.
2. Plumbthebuildinghotwatersupplytothe3/4”
MSPTconnecƟonmarked“WaterOutlet”,which
isthehotwatersupply.
Ifapipecoverwillbeinstalled,makesurewaterlines
tothewaterheaterfit.

ChecklistforPlumbing
පPurgethewaterlineofalldebrisandairby
closingthehotisolaƟonvalveandopeningthe
coldisolaƟonvalveanditsdrain.Debriswill
damagethewaterheater.Useabucketorhose
ifnecessary.
පEnsurethathotandcoldwaterlinesarenot
crossedtotheunitandareleakfree.
පEnsurethatapressurereliefvalveisinstalledwith
araƟngthatexceedstheBTUinputofthewater
heatermodel.RefertotheraƟngplateonthe
sideofthewaterheaterforBTUinput.
පCleantheinletwaterfilterbyclosingthecoldand
hotwaterinletisolaƟon(shutͲoī)valves.Puta
bucketunderthefilterattheboƩomofthewater
heatertocatchanywaterthatiscontainedinside
theunit.Unscrewthewaterfilter.Rinsethe
filtertoremoveanydebris.Installthefilterand
opentheisolaƟonvalves.
පCheckforproperwaterpressuretothewater
heater.Minimumwaterpressureis50psi.Rinnai
recommends60Ͳ80psiformaximum
performance.
InstallaƟonofGasSupply
MUSTDO
x Amanualgascontrolvalvemustbeplacedinthe
gassupplylinetothewaterheater.Aunioncanbe
usedontheconnecƟonabovetheshutoīvalve
forthefutureservicingordisconnecƟonofthe
unit.
x Checkthetypeofgasandthegasinletpressure
beforeconnecƟngthewaterheater.Ifthewater
heaterisnotofthegastypethatthebuildingis
suppliedwith,DONOTconnectthewaterheater.
Contactthedealerfortheproperunittomatchthe
gastype.
x Checkthegassupplypressureimmediately
upstreamatalocaƟonprovidedbythegas
company.Suppliedgaspressuremustbewithin
thelimitsshownintheSpecificaƟonssecƟonwith
allgasappliancesoperaƟng.
x BeforeplacingtheapplianceinoperaƟonalljoints
includingtheheatermustbecheckedforgas
ƟghtnessbymeansofleakdetectorsoluƟon,soap
andwater,oranequivalentnonflammable
soluƟon,asapplicable.(Sincesomeleaktest
soluƟons,includingsoapandwater,maycause
corrosion
orstresscracking,thepipingshallbe
rinsedwithwateraŌertesƟng,unlessithasbeen
determinedthattheleaktestsoluƟonisnonͲ
corrosive.)
x Useapprovedconnectorstoconnecttheunitto
thegasline.Purgethegaslineofanydebris
beforeconnecƟontothewaterheater.
GeneralInstrucƟons
WARNING
1. Ifyouarenotknowledgeableorqualifiedto
installgaslinesorconnecƟons,thencontacta
licensedprofessionaltoinstallthegassupply.
2. Turnoī120vpowersupply.
3. Turnoīthegas.
4. Gasisflammable.Donotsmokeorprovideother
igniƟonsources
whileworkingwithgas.
5. DonotturnonthewaterheaterorgasunƟlall
fumesaregone.

Rinnai RL94e REU-VC2837WD-US Specifications

General

Type	Tankless
Installation	Indoor
Energy Source	Natural Gas or Propane
Flow Rate	9.4 GPM
Energy Factor	0.82
Gas Type	Natural Gas or Propane
Minimum Flow Rate	0.4 GPM
Voltage	120V
Ignition Type	Electronic
Maximum BTU	199, 000 BTU
Temperature Range	98°F to 140°F
Minimum BTU Input	15, 000 BTU/hr
Warranty	12 years heat exchanger, 5 years parts, 1 year labor
