Rinnai RL94e REU-VC2837WD-US User Manual

24 VCSeriesManual
FinalChecklist
ප Thewaterheaterisnotsubjecttocorrosive
compoundsintheair.
ප Thewatersupplydoesnotcontainchemicalsor
exceedstotalhardnessthatwilldamagetheheat
exchanger.
ප Clearancesfromthewaterheaterunitaremet.
ප ClearancesfromtheventterminaƟon/airintake
aremet.
ප Forindoormodels,ensureyouhaveusedthe
correctvenƟngproductsforthemodelinstalled
andthatyouhavecompletelyfollowedthe
venƟngmanufacturer’sinstallaƟoninstrucƟons
andtheseinstallaƟoninstrucƟons.
ප Forindoormodels,verifythattheventsystem
doesnotexceedthemaximumlengthforthe
numberofelbowsused.
ප ForindoormodelsverifythatswitchNo.1inthe
SW1DIPswitch(tanswitches)hasbeenadjusted
forventlengthifnecessary.RefertothesecƟon
onMaximumVentLength.
ප Forindoormodels,verifythattheventpipehasa
downwardslopeorgradetotheoutsideof1/4
inchperfoot(1.2° )ORiftheventpipeissloped
towardthewaterheater(assomelocalcodes
require),thatacondensatecollectorisinstalled
toallowcondensaƟonto
drainawayfromthe
waterheatertoaproperdrainsource.
ප Forindoormodels,verifythatcondensatewillnot
beallowedtodrainbackintothewaterheater.
ප Purgethewaterlineofalldebrisandairby
closingthehotisolaƟonvalveandopeningthe
coldisolaƟonvalveanditsdrain.Debriswill
damagethewaterheater.Useabucketorhose
ifnecessary.
ප Ensurethathotandcoldwaterlinesarenot
crossedtotheunitandareleakfree.
ප Cleantheinletwaterfilterbyclosing thecoldand
hotwaterinletisolaƟon(shutͲoī)valves.Puta
bucketunderthefilterattheboƩomofthewater
heatertocatchanywaterthatiscontainedinside
theunit.Unscrewthewaterfilter.Rinsethe
filtertoremoveanydebris.Installthefilterand
opentheisolaƟonvalves.
ප Ensurethatapressurereliefvalveisinstalledwith
araƟngthatexceedstheBTUinputofthewater
heatermodel.RefertotheraƟngplateonthe
sideofthewaterheaterforBTUinput.
ප Amanualgascontrolvalvehasbeenplacedinthe
gaslinetothewaterheater.
ප CheckthegaslinesandconnecƟonsforleaks.
ප Confirmthatthegasinletpressureiswithin
limits.
ප Confirmthatthewaterheaterisratedforthegas
typesupplied.
ප Confirmthattheelectricityissuppliedfroma120
VAC,60Hzpowersource,isinaproperly
groundedcircuit,andturnedon.
ප VerifythetemperaturecontrollerisfuncƟoning
properly.
ප VerifythatswitchesNo.2andNo.3intheSW1
DIPswitch(tanswitches)issetcorrectlyforyour
alƟtude.
ප Verifythesystem is funcƟoningcorrectlyby
connecƟngyourmanometertothegaspressure
testportonthewaterheater.Operateallgas
appliancesinthehomeorfacilityathighfire.The
inletgaspressureatthewaterheatermustnot
dropbelowthatlistedonthe
raƟngplate.
ප Ifthewaterheaterisnotneededforimmediate
use,thendrainthewaterfromtheheat
exchanger.
ප Installthefrontpanel.
ප Explaintothecustomertheimportanceofnot
blockingtheventterminaƟonorairintake.
ප ExplaintothecustomertheoperaƟonofthe
waterheater,safetyguidelines,maintenance,and
warranty.
ප TheinstallaƟonmustconformwithlocalcodesor,
intheabsenceoflocalcodes,withtheNaƟonal
Fuel Gas Code, ANSI Z223.1/NFPA 54,orthe
Natural Gas and Propane InstallaƟon Code, CSA
B149.1.Ifinstalledinamanufacturedhome,the
installaƟonmustconformwiththeManufactured
Home ConstrucƟon and Safety Standard, Title 24
CFR, Part 3280and/orCAN/SCA Z240 MH Series,
Mobile Homes.
ප InformtheconsumeriftheisolaƟonvalvesare
notinstalledorifawatersoŌeningsystemisnot
installed.
ප LeavetheenƟremanualtapedtothewater
heater(indoormodels),temperaturecontroller
(outdoormodels),orgivetheenƟremanual
directlytotheconsumer.

Rinnai RL94e REU-VC2837WD-US Specifications

General

Type	Tankless
Installation	Indoor
Energy Source	Natural Gas or Propane
Flow Rate	9.4 GPM
Energy Factor	0.82
Gas Type	Natural Gas or Propane
Minimum Flow Rate	0.4 GPM
Voltage	120V
Ignition Type	Electronic
Maximum BTU	199, 000 BTU
Temperature Range	98°F to 140°F
Minimum BTU Input	15, 000 BTU/hr
Warranty	12 years heat exchanger, 5 years parts, 1 year labor
