Rinnai RL94e REU-VC2837WD-US User Manual

 VCSeriesManual 29
PUMP
C
u
t
w
i
r
e
t
o
c
o
n
n
ec
t
t
o
p
u
m
p
RecirculaƟonMode
TheRinnaiwaterheaterhastheabilitytocontrola
recirculaƟonpump.Twomodesareavailable,
EconomyandComfort,whichrecirculatethewaterin
theplumbingsystemtoprovidehotwatermore
quicklywhenatapisopened.
RecirculaƟonmodeisforresidenƟalinstallaƟonsonly.
RecirculaƟon
modecannotbeusedwiththeBathFill
controller(BCͲ100V),anairhandler,orwithmulƟple
Rinnaiwaterheaters.
ThemaximumRinnaitemperatureseƫngwhilein
recirculaƟonmodeis140°F(60°C).
PumpRequirements
Voltage: 120V,60Hz
Amperage: lessthan2amps
NOTE: TheRinnaiPCboardwillbedamagedif
amperageexceeds2Amps.
InͲrushcurrent:Lessthan2.5Amps.
Checkvalve: Anintegralflowcheck(IFC)valveis
required.Seeplumbingdiagram.
PumpSize
Thepumpshouldbesizedfor2.5GPMatthepressure
lossthroughthetanklesswaterheaterandthesupply
andreturnplumbingintherecirculaƟonloop.
FormoreinformaƟononsizingthepumprefertothe
RinnaiCircͲLogic™GuideorthesecƟon“PumpSizing
forCircula
Ɵon”intheRinnaiHotWaterSystem
DesignManual.
InstallaƟon
1. Turnoītheelectricalpowersupplybyunplugging
thepowercordorbyturningoītheelectricityat
thecircuitbreaker.
2. InstalltherecirculaƟonpumponthereturnline
accordingtothepumpmanufacturerinstallaƟon
instrucƟons.Installacheckvalveinthereturn
lineasshown
inthePlumbingDiagramifoneis
notintegratedintothepump.
3. Thewireharnessfortherecirc ula Ɵonpumpis
bundledwiththewirehar nessfromthePCboard.
Theconnectorhasablackandwhitewirewiththe
label“Cutwiretoconnecttopump”.Toconnect
to
thepump,cuttheconnector,splicethewires,
andadd4Ampfusetothehotwire(black)ofthe
pump.Connectthegroundwirefromthepump
toascrewatthebaseofthewatercabinet.
RefertothePumpElectricalConnecƟonDiagram.
FollowElectricalCodeand
pumpmanufacturers 
recommendaƟons.
4. Adjustthedipswitchbymovingthe4thswitchin
thewhiesetofswitches(SW2)toON.
ForEconomymode,setthe8thswitchinthe
whitesetofswitches(SW2)toOFF(default).
ForComfortmode,setthe8thswitchinthewhite

setofswitches(SW2)toON.
5. Connect powertothewaterheater.Pressthe
PowerbuƩononthecontroller.Thepumpand
waterheaterwillturnontoraisetherecirculaƟon
looptemperature.

SeƫngsforSW2
(bankofwhiteswitches)

Switch4 Switch8
Economy
Mode ON OFF
ComfortMode ON ON
Cutconnector
andsplicewires.
PC
Board
PumpElectricalConnecƟon
4Amp
Fuse
BL
W
PlumbingDiagram
NOTE: DONOTinstalltheRinnaiScaleControlsystem
withintherecirculaƟonloop.
HOT W ATER
SUPPLYLINE
(minimum3/4”)
COLD WATERSUPPLYLINE
PUMP
ELECTRICAL
CONNECTION
(POWER)
RECIRCULATION
LOOP
HOT WATEROUTLETS
CHECK VALVE
(REQUIRED)
CHECK
VALVE
THERMAL
EXPANSION TANK
RINNAI
SCALE
CONTROL
(RECOMMENDED)
RETURNLINE
(minimum3/4”)

Rinnai RL94e REU-VC2837WD-US Specifications

General

Type	Tankless
Installation	Indoor
Energy Source	Natural Gas or Propane
Flow Rate	9.4 GPM
Energy Factor	0.82
Gas Type	Natural Gas or Propane
Minimum Flow Rate	0.4 GPM
Voltage	120V
Ignition Type	Electronic
Maximum BTU	199, 000 BTU
Temperature Range	98°F to 140°F
Minimum BTU Input	15, 000 BTU/hr
Warranty	12 years heat exchanger, 5 years parts, 1 year labor
