Rinnai RL94e REU-VC2837WD-US User Manual

 VCSeriesManual 13
Manufacturer
ListedandTestedVentProducts
Telephone Fax Contact
Ubbink RoluxVentSystem 800Ͳ621Ͳ9419 678Ͳ829Ͳ1666 www.rinnai.us
HeatͲFab SafͲTVentSCsystem 800Ͳ772Ͳ0739 413Ͳ863Ͳ4803
custsvc@heatͲfab.com,
www.heaƞab.com
MetalͲFab Corr/GuardVent/AirIntakeSystem 800Ͳ835Ͳ2830 316Ͳ943Ͳ2717
info@mtlfab.com,
www.metal
Ͳfabinc.com
InstallaƟonofvenƟng(indoormodelsonly)
InstallthecorrectvenƟngforyourmodelaccordingtothevenƟngmanufacturer’sinstrucƟonsandthe
guidelinesbelow.
Refertothemanufacturer’stechnicalliteratureforspecificpartnumbersandinstrucƟons.
VenƟngGuidelines                 
DONOT
x DonotusePVC,CPVC,ABSorgalvanizedmaterial
toventthisappliance.
x Donotcombineventcomponentsfromdiīerent
manufacturers.
x Ventdiametermustnotbereduced.
x DonotconnectthevenƟngsystemwithan
exisƟngventorchimney.
x Donotcommonventwiththeventpipeofany
otherwaterheaterorappliance.
MUSTDO
x Thiswaterheaterisadirectventwaterheaterand
thereforeiscerƟfiedandlistedwiththevent
system.Youmustuseventcomponentsthatare
cerƟfiedandlistedwiththewaterheatermodel.
x Theventsystemmustventdirectlytotheoutside
ofthebuildinganduseoutsideairforcombusƟon.
x Avoiddipsorsagsinhorizontalventrunsby
installingsupportspertheventmanufacturer’s
instrucƟons.
x Supporthorizontalventrunseveryfourfeetand
allverƟcalventrunseverysixfeetorin
accordancewithlocalcodes.
x VenƟngshouldbeasdirectaspossiblewitha
minimumnumberofpipefiƫngs.
x VentconnecƟonsmustbefirmlypressedtogether
sothatthegasketsformanairƟghtseal.
x Theventpiececonnectedtothewaterheater
mustbesecuredwithoneselfͲtappingscrew.
INFORMATION
x RefertotheinstrucƟonsoftheventsystem
manufacturerforcomponentassembly
instrucƟons.
x Iftheventsystemistobeenclosed,itissuggested
thatthedesignoftheenclosureshallpermit
inspecƟonoftheventsystem.Thedesignofsuch
enclosureshallbedeemedacceptablebythe
installerorthelocalinspector.
NOTICE
Ifitbecomesnecessarytoaccessanenclosedvent
systemforserviceorrepairs,Rinnaiisnotresponsible
foranycostsordiĸculƟesinaccessingthevent
system.Thewarrantydoesnotcoverobtaining
accesstoaventsysteminanenclosedenvironment.

Rinnai RL94e REU-VC2837WD-US Specifications

General

Type	Tankless
Installation	Indoor
Energy Source	Natural Gas or Propane
Flow Rate	9.4 GPM
Energy Factor	0.82
Gas Type	Natural Gas or Propane
Minimum Flow Rate	0.4 GPM
Voltage	120V
Ignition Type	Electronic
Maximum BTU	199, 000 BTU
Temperature Range	98°F to 140°F
Minimum BTU Input	15, 000 BTU/hr
Warranty	12 years heat exchanger, 5 years parts, 1 year labor
