Rinnai RL94e REU-VC2837WD-US User Manual

 VCSeriesManual 17
IsolaƟonValvesandPressureReliefValve
TheisolaƟonvalvesprovidetheabilitytoisolatethe
waterheaterfromthestructure’splumbingandallow
quickaccesstoflushtheheatexchanger.Checkwith
localcodestodetermineifapressureand
temperaturereliefvalveisrequired.Theincluded
valvesmeetAmerican NaƟonal Standard (ANSI
Z21.10.3) / Canadian Standard (CSA 4.3)andare
ANSI/NSF61
approvedforpotablewater.
IsolaƟonValvesInstallaƟonInstrucƟons:
1. Wraptheendsofthethreadedwaterinlet&
outletonthetanklesswaterheater,aswellas
thethreadedendoftheapprovedpressurerelief
valvewithaminimumof5wrapsofTeflon®
tape.
2.
 Screwthepressurereliefvalveintothe3/4”
threadsoppositethewinghandleontheHOT
waterservicevalve.(REDdrainhandle)(see
PressureReliefValveSecƟonforproper
installaƟonrequirements)
3. Loosenthe3/4”unionnutontheHOTwater
valveandconnecttotheHOTwater
outleton
thetanklesswaterheater.Ifnutisremoved,
ensurethatyourealignthetailpieceaccurately
tothevalveandthattheblackwasheris
posiƟonedsuchthattheraisedmetaledgeof
thevalveisinsidethewasher.
4. AlignthedirecƟonoftheHOTwaterdrain
tothe
desiredposiƟon.
5. TightentheunionassemblytotheHOTwater
valveusingapproximately15footlbsoftorque.
6. Repeatsteps3Ͳ5fortheCOLDwatervalve.
(BLUEdrainhandle)forconnecƟontotheCOLD
waterinletonthetanklesswaterheater.
7. Connect
theINLETontheCOLDwatervalveto
theMAINSOURCEofthewatersupply.
8. ConnecttheOUTLETontheHOTwatervalveto
theHOTWATERplumbingsystem.
9. Ensurethatbothdrainvalveleverhandlesarein
theclosedposiƟon(perpendiculartothedrain
porƟonof
thebody).
PressureReliefValveInstallaƟonInstrucƟons:
ThePRVmustbeconnectedbythethreaded
connecƟonoppositethewinghandleonthehot
watervalve(designatedbytheREDdrainhandle)or
thethreadedconnecƟononthesideoftherelocaƟon
fiƫngabovethe
hotwatervalve.InstallaƟonmust
maintaina¾”portsizewithnoshutoīvalveorline
restricƟoninͲbetweentheapplianceandthePRV.The
dischargelinefromthePRVshouldpitchdownward
andterminate6”abovedrainswheredischargewill
beclearlyvisible.Thedischargeendof
thelineshall
beplain(unthreaded)andaminimumof¾”in
diameter.Thedischargelinematerialmustbe
suitableforwateratleast180°Fahrenheitandcanbe
nomorethan30feetinlengthandcontainnomore
than4elbowsorbends.Novalveofanytype
maybe
installedinthedischargelineofthepressurerelief
valve.
PressureReliefValveMaintenance:
Forpropercareofthisapprovedpressurereliefvalve,
itisrecommendedthatthevalveismanually
operatedonceayear.Indoingso,itwillbenecessary
totakeprecauƟonswithregardto
thedischargeof
potenƟallyscaldinghotwaterunderpressure.Ensure
dischargehasaplacetoflow.Contactwithyourbody
orotherpropertymaycausedamageorharm.
PleasenotethatonlythePRVinthispackageis
cerƟfiedbyCSAInternaƟonalasanapproveditem.
A PressureReliefValve(PRV)
B PRVDischargeOutlet
C HotBallValveDrainHandle
D ColdBallValveDrainHandle
A
B
C
D

Rinnai RL94e REU-VC2837WD-US Specifications

General

Type	Tankless
Installation	Indoor
Energy Source	Natural Gas or Propane
Flow Rate	9.4 GPM
Energy Factor	0.82
Gas Type	Natural Gas or Propane
Minimum Flow Rate	0.4 GPM
Voltage	120V
Ignition Type	Electronic
Maximum BTU	199, 000 BTU
Temperature Range	98°F to 140°F
Minimum BTU Input	15, 000 BTU/hr
Warranty	12 years heat exchanger, 5 years parts, 1 year labor
