AGM - Installation and Programming Instructions 11
7. Inputs
The AGM has four inputs, which NC and NO devices can be connected to.
Inputs can be activated by negative or positive remove according to the J15 Jumper
position.
Each input event and its restore can be reported to the Monitoring Station (by SMS or
GPRS) or to any of the 8 Follow Me destinations ( by SMS, Voice message or Email)
Triggering of input event can be defined to be immediate or after a delay.
Each input can be defined as a 24-hour type (constantly activated) or as an Arm/Disarm
type (activated or deactivated by a remote SMS user command).
Input 3 can also be defined as type “Switch from PSTN to GSM”. When a phone line is
connected to the AGM, the user has the ability to manually switch the outgoing line from
PSTN to GSM (Latch operation).
Input 4 can also be defined as type “Stop Follow Me”. When triggered, it will stop all
Follow Me calls following the current event
.
8. Outputs
The AGM has four outputs (one 3A relay output and three-100mA Open Collector
outputs) that can be activated automatically according to various events, or manually,
by SMS commands from pre defined Follow Me telephone numbers. Each output can
be defined to be pulsed or latched
.
8.1 Output Events
Output defined as “Follow Event” can automatically be activated by the following events:
Ê Input 1 - 4 event: Activates following triggering / restore of an input.
Ê Tamper: Activates following AGM tamper alarm.
Ê PSTN Lost: Activates following a loss of PSTN line (connected to the GSM).
The output will be activated after the defined PSTN Loss Delay time.
Ê GSM Trouble: Activates in the following cases:
x There is no SIM card in the AGM or SIM is faulty
x GSM RSSI signal level is low
x GSM network trouble
Ê Mains power Loss: Activates when the source of the main AC power is
interrupted. The output will be activated after the predefined AC Loss Delay
time.
Ê Low Battery: Activates when the AGM battery has insufficient reserve capacity
and the voltage is lower than 11V.
Ê SIM Card Expire: Activates 30 days before the time defined in the SIM Expire
timer.
Ê Periodic Test: Activates following the time defined in the Periodic Test timer.
Ê GSM+PSTN Loss: Activates following loss
of PSTN and GSM network.
