16 AGM - Installation and Programming Instructions
11.2 SMS Programming Commands
The table below provides the entire set of commands available. The procedure of
programming the commands is identical and uses the same syntax as described in the
previous section. The order of the commands is identical to the order in the AGM
Configuration Software.
Command Description Programming Options Default
Parameters
Standard Parameters : Settings
RLMD:AGM Operation Mode
Configures the AGM module mode of operation. For more
details see page 17.
0: GSM Backup
1: GSM Only
2: GSM Main
0
RSST:GSM Network Sensitivity
Set the minimum acceptable network signal level (RSSI
level).
1: Low Signal
2: Average Signal
3: High Signal
2
Standard Parameters : Timers
PSLT: PSTN Loss Delay
The time after which the AGM will switch over to the GSM
network following PSTN loss.
10 to 255 seconds 10 sec.
GSLT: GSM Loss Delay
The time after which the AGM will switch over to the PSTN
line following GSM network loss.
1 to 255 minutes 4 min
MTDT: AC Loss Delay
In case of AC power loss, this parameter specifies the
delay time before reporting the event or operating the
output.
0 to 255 minutes 30
minutes
Standard Parameters :Controls
CLDG: Caller ID
The Caller ID function enables the AGM to restrict SMS
remote control operations to predefined Follow Me phone
numbers.
0: Caller ID deactivated. The AGM can receive SMS
control messages from any phone number.
6: Caller ID activated. The AGM can receive SMS control
messages only from recognized Follow Me numbers.
The AGM checks the last 6 digits of the telephone
number from which the SMS was sent from and
compares them to the last digits of the Follow Me
numbers defined in the AGM. If the digits coincide, the
number is recognized and the operation will be
executed.
0: Caller ID deactivated
6: Caller ID activated
0
ICDS: Incoming Call Disable
This parameter is used to disable all incoming calls trying
to come in via the GSM voice channel. When this
parameter is enabled, SMS or Remote programming is still
allowed.
0: Incoming voice call
enabled
1: Incoming voice call
disabled
0
Standard Parameters :Access Codes
PWFM: User Code
4 digit user code for remote SMS system operations
4 digits 1234
PWIN: Installer Code
4 digit code used for remote SMS or PC Software
4 digits 0200
