Risco AGM - Technical Specifications

22 AGM - Installation and Programming Instructions
12.Technical Specifications
Electrical Characteristics
Voltage 230 V/110 V AC / 14,5 V DC (0,8 A)
During Communication - 300mA Current Consumption
During Standby - 70mA
Battery (not supplied) 12VDC/1.2Ah
Battery Type: Lead Acid (rechargeable)
Battery Dimensions Width x
Height x Depth
97 x 58 x 43 mm (3.8” x 2.3” x 1.7”)
GSM Industrial Module Quad Band GSM 850/900/1800/1900MHz
Connection RS-485 Serial Link
Operating Temperature 0°C to 55°C (32°F to 131°F)
Physical characteristics
Dimensions (metal casing)
Width x Height x Depth
185 x 275 x 65 mm (7.2” x 10.8” x 2.6”)
With antenna installed:
185 x 335 x 65 mm (7.2” x 13.2” x 2.6”)
Weight (with battery) 2.1kg (4.6lbs)
