14 AGM - Installation and Programming Instructions
11. AGM Programming
The AGM can be programmed via a standard PC, using the AGM Configuration
Software application, or, via any GSM cellular phone, using SMS commands.
Programming the AGM with the AGM Configuration Software can be performed using
three options:
Ê Locally: Connect the AGM to the PC using RISCO Group's cable adaptor
(RP128EUSB00A).
Ê Remotely: Remote programming is performed using the GSM data channel at 9600
bps.
Notes:
1. When calling the AGM from a PSTN line or from a different provider, the Data channel
(CSD) in the SIM card should be enabled.
2. When calling the AGM from a number of the same provider the data channel is
automatically enabled (Data number not required).
Ê By SMS: The AGM Configuration Software enables to send each parameter as a
single SMS command or the entire screen, as if sent from a regular GSM cellular
phone.
11.1 Installer SMS Programming
The AGM can be programmed using predefined SMS commands (see page 16) from any
standard GSM cellular phone. Before any command line, a valid installer code should be
used. Default installer code is 0200.
1. Sending a Single SMS Command (see page 16)
[Installer code] [4-digit Programming command] [=] [Programming data]
Example: Setting User Code (see page 17):
Installer code = 0200; Setting user code command=PWFM; New code=4444
0200PWFM=4444
2. Sending a Single SMS Command with Multiple Data (see page 19)
Use [,] to separate between data of the same command
Example: Setting events to Follow Me number 1 (see page 20):
Installer code = 0200; Command=F1RE Events: 1 (Input 1), 5 (Tamper), 8 (AC loss)
0200 F1RE =1,5,8
