Risco AGM - Diagnostics

AGM - Installation and Programming Instructions 21
Command Description Programming Options Default
RI4R Input 4 restore event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0100
(Medical)
RPSE PSTN event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0351
RPSR PSTN restore event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0351
RACE AC loss event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0301
RACR AC loss restore event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0301
RLBE Low battery event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0302
RLBR Low battery event restore 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0302
RTME Tamper event 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0137
RTMR Tamper restore 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0137
RPTE Periodic test 4 digits (MSCF=0420)
2 chars (MSCF=0700)
0602
Diagnostics (can be performed by the installer and/or the user)
SFTR: Software Version
Sending the SFTR command to the
AGM will return the current AGM
software version
SMS Structure: [Code][SFTR][?]
Example: 0200SFTR?
Installer only
ST: AGM Status
Sending the ST command to the AGM
will return the status of the AC power,
Battery status, PSTN line status and
GSM signal level.
SMS Structure: [Code][ST]
Example: 1234ST
User only
STI: Inputs Status
Sending the STI command will return
the current input status (On/Off).
SMS Structure: [Code][STI]
Example: 1234STI
User only
STO: Outputs Status
Sending the STO command will return
the current outputs status (Activated /
Not -activated)
SMS Structure: [Code][STO]
Example: 1234STO
User only
CLK: Receiving AGM time and date
Sending the CLK command allows
receiving the actual AGM TIME
SMS Structure: [Code][CLK]
Example: 1234CLK
Installer/User
CLK: Changing AGM time and date
Sending the CLK command allows
changing the AGM time and date.
SMS Structure:
[Code][CLK][dd/mm/yy,hh,mm]
Example:
1234CLK10/12/06,12,30
Installer/User
