ELECTRICAL WIRING CHARTS
Average Motor Loads (Amps)
Air Hydraulic Leveler
Levelers 3/4 hp 1hp
110-120/1 12.0 10.0 14.5
208-230/1 7.0 5.0 7.2
208-230/3 N/A N/A 4.4
380-415/3 N/A N/A 2.4
440-480/3 N/A N/A 2.2
575-600/3 N/A N/A 1.7
Minimum Wire Size Chart for Various Line Lengths and Line Loads
Line Length (In Feet)
0-50 51-100101-150 151-200 201-205 251-300 301-350 351-400
110-120/1 1300 watts Air Powered Levelers 12 8 6 6 4 4 3 2
110-120/1 3/4 hp Hydraulic Levelers 12 10 8 6 4 4 4 3
110-120/1 1 hp Hydraulic Levelers 10 8 6 4 4 3 2 1
208-240/1 1533 watts Air Powered Levelers 14 14 12 10 10 8 8 8
208-240/1 3/4 hp Hydraulic Levelers 14 14 14 12 10 10 10 8
208-240/1 1 hp Hydraulic Levelers 14 12 12 10 8 8 8 6
208-240/3 1hp Hydraulic Levelers 14 14 12 12 10 10 10 8
380-415/3 1 hp Hydraulic Levelers 14 14 14 14 14 14 14 14
440-480/3 1 hp Hydraulic Levelers 14 14 14 14 14 14 14 14
575-600/3 1 hp Hydraulic Levelers 14 14 14 14 14 14 14 14
