Rittal Blue e+ fan-and-filter unit assembly and operating instructions 23
EN
Accessories
Blanking cover for fan-and-filter unit / outlet filter
To fit Model No. IP protection category in accordance with IEC 60529 Packs of Model No.
3237.xxx IP54 2 pc(s). 3237.021
3238.xxx IP54 2 pc(s). 3238.020
3239.xxx IP54 2 pc(s). 3239.020
3240.xxx/3241.xxx IP54 2 pc(s). 3240.020
3243.xxx/3244.xxx IP54 2 pc(s). 3243.020
Tab. 16: Blanking cover for fan-and-filter unit / outlet filter
Hose-proof hoods
To fit Model No. W x H x D mm Protection category Packs of Model No.
3237.xxx 150 x 230 x 40 NEMA1, NEMA12, NEMA3, NEMA3R 1 pc(s). 3237.080
3238.xxx 176 x 245 x 55
NEMA1, NEMA12, NEMA3, NEMA3R,
NEMA4, NEMA4X
1 pc(s). 3238.080
3239.xxx 233 x 330 x 55
NEMA1, NEMA12, NEMA3, NEMA3R,
NEMA4, NEMA4X
1 pc(s). 3239.080
3240.xxx/3241.xxx 282 x 390 x 85
NEMA1, NEMA12, NEMA3, NEMA3R,
NEMA4, NEMA4X
1 pc(s). 3240.080
3243.xxx/3244.xxx 350 x 480 x 110
NEMA1, NEMA12, NEMA3, NEMA3R,
NEMA4, NEMA4X
1 pc(s). 3243.080
Tab. 17: Hose-proof hoods
Safety clip
To fit Model No. Packs of Model No.
3237.xxx/3238.xxx 1 pc(s). 3201.940
3239.xxx/3240.xxx/3241.xxx/3243.xxx/3244.xxx 1 pc(s). 3201.941
Tab. 18: Safety clip
