Rittal Blue e+ fan-and-filter unit assembly and operating instructions 13
EN
Technical specifications
10 Technical specifications
◾ Observe the mains connection data (voltage and
frequency) as per the rating plate.
◾ Observe the pre-fuse as per the specifications on the
rating plate.
Unit Model No.
Fan-and-filter unit RAL7035 3237.700 3237.710 3237.724
Fan-and-filter unit RAL9005 3237.708 3237.718 –
EMC fan-and-filter unit RAL7035 3237.800 3237.810 –
Electrical specifications
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
Rated current max. A 0.10/0.09 0.14/0.13 0.06
Tolerance rated operating voltage % ±10
Power consumption W 13.0/11.1 12.0/10.0 1.4
Pre-fuse T A 2
Motor circuit-breaker A –
Air throughputs (further information can be found in the characteristic curves on the Rittal homepage)
Unimpeded airflow with chopped-fibre filter m³/h 20/25 20
With outlet filter including chopped-fibre filter m³/h 15/18 15
Unimpeded airflow with pleated filter m³/h –
With outlet filter including pleated filter m³/h –
Other
Weight (net) kg 0.4 0.4 0.24
Fan Axial, shaded pole motor Axial, DC motor
Fan bearing Ball bearing
Noise pressure level dB (A) 42/47 42/47 42
Operating temperature °C -15…+55
Storage temperature °C -30…+70
Protection category (to IEC 60 529)
IP54 with chopped-fibre filter (standard)
IP56 with hose-proof hood
Protection category (according to NEMA)
NEMA 12 with chopped-fibre filter (standard)
NEMA 3, 3R with hose-proof hood
Outlet filter
RAL7035 3237.300
RAL9005 3237.308
EMC RAL7035 3237.400
Tab. 3: Technical specifications Technical modifications reserved.
