14 Rittal Blue e+ fan-and-filter unit assembly and operating instructions
EN
Technical specifications
Unit Model No.
Fan-and-filter unit RAL7035 3238.700 3238.710 3238.724
Fan-and-filter unit RAL9005 3238.708 3238.718 –
EMC fan-and-filter unit RAL7035 3238.800 3238.810 3238.824
Electrical specifications
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
Rated current max. A 0.10/0.12 0.20/0.21 0.27
Tolerance rated operating voltage % ±10
Power consumption W 14.7/16.5 15.4/15.8 5.7
Pre-fuse T A 2
Motor circuit-breaker A –
Air throughputs (further information can be found in the characteristic curves on the Rittal homepage)
Unimpeded airflow with chopped-fibre filter m³/h 53/64 53
With outlet filter including chopped-fibre filter m³/h 40/46 40
Unimpeded airflow with pleated filter m³/h 63/72 63
With outlet filter including pleated filter m³/h 49/55 49
Other
Weight (net) kg 0.68 0.68 0.42
Fan Axial, shaded pole motor Axial, DC motor
Fan bearing Ball bearing
Noise pressure level dB (A) 52/54 52/54 52
Operating temperature °C -15…+55
Storage temperature °C -30…+70
Protection category (to IEC 60 529)
IP54 with chopped-fibre filter
IP54 with pleated filter (standard)
IP55 with pleated filter and absorber mat
IP56 with hose-proof hood
Protection category (according to NEMA)
NEMA 12 with chopped-fibre filter
NEMA 3, 3R, 4, 4X with hose-proof hood
Outlet filter
RAL7035 3238.300
RAL9005 3238.308
EMC RAL7035 3238.400
Tab. 4: Technical specifications Technical modifications reserved.
