Technical specifications
Unit Model No.
Fan-and-filter unit RAL7035 3239.700 3239.710 3239.724
Fan-and-filter unit RAL9005 3239.708 3239.718 –
EMC fan-and-filter unit RAL7035 3239.800 3239.810 3239.824
Electrical specifications
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
Rated current max. A 0.10/0.12 0.20/0.21 0.27
Tolerance rated operating voltage % ±10
Power consumption W 14.7/16.5 15.4/15.8 5.7
Pre-fuse T A 2
Motor circuit-breaker A –
Air throughputs (further information can be found in the characteristic curves on the Rittal homepage)
Unimpeded airflow with chopped-fibre filter m³/h 100/115 100
With outlet filter including chopped-fibre filter m³/h 75/86 75
Unimpeded airflow with pleated filter m³/h 110/125 110
With outlet filter including pleated filter m³/h 92/104 92
Other
Weight (net) kg 0.92 0.92 0.66
Fan Axial, shaded pole motor Axial, DC motor
Fan bearing Ball bearing
Noise pressure level dB (A) 51/54 51/54 51
Operating temperature °C -15…+55
Storage temperature °C -30…+70
Protection category (to IEC 60 529)
IP54 with chopped-fibre filter
IP54 with pleated filter (standard)
IP55 with pleated filter and absorber mat
IP56 with hose-proof hood
Protection category (according to NEMA)
NEMA 12 with chopped-fibre filter or pleated filter (standard)
NEMA 3, 3R, 4, 4X with hose-proof hood
Outlet filter
RAL7035 3239.300
RAL9005 3239.308
EMC RAL7035 3239.400
Tab. 5: Technical specifications Technical modifications reserved.
