16 Rittal Blue e+ fan-and-filter unit assembly and operating instructions
EN
Technical specifications
Unit Model No.
Fan-and-filter unit RAL7035 3240.700 3240.710 3240.724
Fan-and-filter unit RAL9005 3240.708 3240.718 –
EMC fan-and-filter unit RAL7035 3240.800 3240.810 –
Electrical specifications
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
Rated current max. A 0.20/0.21 0.41/0.42 0.42
Tolerance rated operating voltage % ±10
Power consumption W 33.1/37.3 35.5/38.2 10.1
Pre-fuse T A 2 4 2
Motor circuit-breaker A –
Air throughputs (further information can be found in the characteristic curves on the Rittal homepage)
Unimpeded airflow with chopped-fibre filter m³/h 175/157 175
With outlet filter including chopped-fibre filter m³/h 130/112 130
Unimpeded airflow with pleated filter m³/h 218/191 218
With outlet filter including pleated filter m³/h 191/161 191
Other
Weight (net) kg 1.82 1.82 1.44
Fan Diagonal, shaded pole motor Diagonal, DC motor
Fan bearing Ball bearing
Noise pressure level dB (A) 48/45 48/45 48
Operating temperature °C -30…+55
Storage temperature °C -30…+70
Protection category (to IEC 60 529)
IP54 with chopped-fibre filter
IP54 with pleated filter (standard)
IP55 with pleated filter and absorber mat
IP56 with hose-proof hood
Protection category (according to NEMA)
NEMA 12 with chopped-fibre filter or pleated filter (standard)
NEMA 3, 3R, 4, 4X with hose-proof hood
Outlet filter
RAL7035 3240.300
RAL9005 3240.308
EMC RAL7035 3240.400
Tab. 6: Technical specifications Technical modifications reserved.
