24 Rittal Blue e+ fan-and-filter unit assembly and operating instructions
EN
Connection diagrams
14 Connection diagrams
M
3~
L1 L2 L3 PE L N PE
M
1~
L NPE
M
1~
LN PE
M
24 V DC
–24 +
M
1~
3237 .700/.708/.710/
.718/.800/.810
3238 .700/.708/.710/
.718/.800/.810
3239 .700/.708/.710/
.718/.800/.810
3243 .700/.708/.710/
.718/.800/.810
3244 .700/.708/.710/
.718/.800/.810
3240 .700/.708/.710/
.718/.800/.810
3241 .700/.708/.710/
.718/.800/.810
3244.740 3237.724
3238.724/.824
3239.724/.824
3240.724
3241.724
Fig.23: Connection diagrams
