Rittal VX IT Series User Manual

59
Schranksystem VX IT / VX IT enclosure system / Baies VX IT
6.1
5
6.2
F
F
F
7
5 x 12
M
A
= 5 Nm
F
8
M
A
= 5 Nm
F
5 x 12
1
2.2
2.1
4. Montage und Aufstellung
4. Assembly and siting
4. Montage et implantation
TX30
F
R
R
4
5 x 12
M
A
= 5 Nm
R
R
3
5 x 12
M
A
= 5 Nm
R
2 3
6 7
5 8
5 8
6 7
1 4
2 3
1 4
Tiefenverstellung der 19˝-Ebene,
Rackbreite 800 mm, Racktiefe 1000/1200 mm
Depth adjustment of the 482.6 mm (19˝) level,
rack width 800 mm, rack depth 1000/1200 mm
Réglage en profondeur du plan 19˝,
largeur de baie 800 mm, profondeur de baie 1000/1200 mm
4.3.8 Aufstellung vorbereiten
4.3.8 Preparing for installation
4.3.8 Préparer la mise en place
Profi lschienen system dynamic
Mounting angle system, dynamic
Montants « dynamic »

Rittal VX IT Series Specifications

General

Color	RAL 7035
Protection category	IP55
Width	600 mm
Depth	1000 mm
Weight	Varies by model
Door Type	Single door
