7. Working life
75
DeutschEnglishFrancaisEspanolItaliano
7.11 Operating the 6-key hand switch
You control drives with the keypad on the hand switch. You can also store positions for a specific
user or set the controls.
7.11.1 Overview of the 6-key hand switch
7.11.2 Drive up to position manually
• Press the DOWN or UP key and keep the relevant key
pressed until the drive has moved into the desired
position.
The position of the drive appears in the display.
1
Function key
Select and display settings
(e.g. a user or a position)
2
Drive DOWN
The drive moves when the key is pressed.
3
Drive UP
The drive moves when the key is pressed.
4
Hot keys 1 to 3
Selecting and driving up to user-specific positions or
carrying out settings
A
Display
Display the current position, settings and error
messages
Ensure that nobody is in the vicinity of the drives when they are moving.
Therefore, only use the hand switch if you can see the drives - danger - risk of
accident!
