7. Working life
76
7.12 Storing and driving up to positions
Besides moving the drives manually with the UP and DOWN keys, you can also store positions and
drive up to these.
Up to 3 users can store up to 3 positions each, i.e. up to 9 positions in all.
We recommend that you use position storage only if the drives have to be driven by different us-
ers into constantly recurring positions.
7.12.1 Storing positions
A position is stored in a 2-step sequence.
In the first step, the user gives his instructions via a user level.
In the second step, the position is placed on a storage key.
7.12.2 Determining users
Example: You want to store your positions as user 1.
• Press the F key until the last selected user appears in
the display (e.g. "USE.3").
• Press storage key I within 5 seconds. "USE.1“ ap-
pears in the display.
Yo
u have selected user 1.
Now you can store a position on a hot key as user 1.
