-5-
(1) Input type selection ( )
Set-value (SV) display unit
VALUE INPUT TYPE HARDWARE
K
J
L
E
N
a
TC
R
S
B
W5Re / W26Re
PLII
T
U
b
Pt100 S (JIS / IEC)
RTD
J Pt100 S (JIS)
c
0 to 5 V DC
Voltage
1 to 5 V DC
d
0 to 20 mA DC
Current
4 to 20 mA DC
e
Cautions
1. Conduct setting so as to meet the instrument specification (input type).
Setting change between different symbols may cause malfunction, but the setting can be changed when
hardware types have the same symbol. However, when the setting is changed, always reset “ ” and
“ ”. (See page 14).
2. “ ” setting displays are only “ ”and “ ”.
To Next Page
