33
Section 3 - Slate Bolt Installation
Place the panels in the correct position. In case of systems with more than two panels, mount
the panels starting in the middle. Do not forget to secure the panels together with any straight
connectors required (supplied in panel extension set) Mount the wind clamps [14] and connect the
panels.
Design of the wind clamps may vary - this will not effect the performance of the roof frame.
14
15
14
15
