50
Section 4 - In Roof Frame Installation
Nail Straps
Fix top ashings (16/17/18/19) with 2 nail strips and side ashing (12/13) with 4 nail strips (20) each.
Stick wedge formed seal (21) across the total length. It must be placed so that after replacing the
tiles it will be approximately 5cm under the bottom tile edge.
NOTE: Seal (21) must be placed at least 10cm down the side ashings (16/19).
Additional seal can be ordered from the outlet where the kit was purchased.
min. 10 cm
21
20
