34
Section 4 - In Roof Frame Installation
In Roof Frames - S Class 20
The In roof frames from RM Solar come in the following two styles, choosing the correct frame for
your installation is paramount to an effective install. Minimum roof pitch for installation is 28
o
Tile In Roof
The tile in roof has a shallower prole to accommodate the panels with the thicker roof covering, a
exible corrugated lead ashing is also present to allow moulding to a rolling tile.
Slate In Roof
The slate in roof has a deeper prole to accommodate the panels with the thinner roof covering.
Currently the S Class 20 Panel can only be installed In Roof up to 3 panels, and cannot be installed
using the “parallel” method.
