RM Solar S Class 10 - Mount Side Flashings

46
Section 4 - In Roof Frame Installation
Mount Side Flashings
Push the side ashing (12/13) from the side over the collector edge. Use sealing screws (25) to x
the ashings as shown. Be Careful! Do not bend the ashings. The 8” long slit on the side ashings
goes at the bottom of the collectors and allows the ashing to ex onto the roof covering.
12
13
12
13
25
22
13
