OPERATION
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
Manual EC 24 · EN05 · 2015-02
20
Coordinate system
Pointer position V V· P T
Designation Totalizers Flow Rate Pressure Temperature
Coordinate / Line A B C D
1 Volume at base conditions Qb bara °C
2 Volume at measurement conditions Qm p min t min
3 Disturbing quantity totalizer Vb Frequency p max t max
4 Disturbing quantity totalizer Vm Qm min pb specified value tb specified value
5 Pulse scaling factor Qm max p default t default
6 Meter factor Qm max val. p binary display Factor adjustment value
7 Switch-off Qm Binary value at 0.5 V Offset adjustment value
8
Time limit for
Q < Qm.min
Binary value at 4.5 V AD binary value
9 Monthly data memory U min
10 Monthly data memory pu min
11 Monthly data memory Rise
12 Monthly data memory Factor correction value
13 Monthly data memory Offset correction value
14 ... 22 Monthly data memory
Pointer position C Io Error / Type Mode
Designation Analysis Outputs Error / ID Mode / Memory
Coordinate / Line E F G Z
1 Conversion factor Current Error text TerzMode
2 K coefficient Current min Software version EcMode
3 K specified value Current max Serial number Puls_X
4 Hs Current default Checksum Puls_Y
5 Rhon Current rise Ser. no. pressure transmitter Time
6 CO2 Current offset p min Date
7 Zb Current damping p max Modbus address
8 Z Ser. no. temperature transmitter ModbusRegOffset
9 Hs ref temp T min Error bit string
10 N2 T max Wake-up pulse
11 rd Ser. no. meter Code number
12 Meter size Beginning of gas day
13 Battery change EcMode2
14 Charge no.
15 K factor formula
16 Change of code number
