OPERATION
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
Manual EC 24 · EN05 · 2015-02
23
Temperature
Pointer position
T
Coding
Coordinate /
Line
D
Description of the coordinate Unit Special feature
D 1 °C Measured temperature value °C
S 2 T< Lower fault limit °C
S 3 T> Upper fault limit °C
S 4 Tb Specified value, temperature at base conditions °C
C 5 T-def Default value, temperature °C
S 6 T-F Adjustment value (factor)
S 7 T-O Adjustment value (offset)
D 8 Dig Binary value of AD converter
Analysis
Pointer position
C
Coding
Coordinate /
Line
E
Description of the coordinate Unit Special feature
D 1 C Conversion factor 1
D 2 K K coefficient 1
C 3 K-V Specified value, K coefficient (if K=const) 1
C 4 Hon Superior calorific value
KWh/m
3
C 5 rhn Rhon Kg/m3
C 6 CO2 Carbon dioxide content %
D 7 Zb Compressibility factor at base conditions 1
D 8 Z Compressibility factor at measurement conditions 1
S 9 TB Reference temperature, superior calorific value °C
C 10 N2 Nitrogen content (for AGA-NX-19) %
C 11 dv Relative density (for AGA-NX-19) 1
Outputs
Pointer position
Io
Coding
Coordinate /
Line
F
Description of the coordinate Unit Special feature
D 1 mA Current out mA
C 2 I< Value at 4 mA mA
C 3 I> Value at 20 mA mA
C 4 I-def Current default mA
C 5 I-F Current rise
C 6 I-O Current offset
C 7 I-D Current damping
