RMG EC 24 - Dimensions

ANNEXES
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
Manual EC 24 · EN05 · 2015-02
44
F Dimensions
Drwg. no.
MESSTECHNIK GMBH
35510 Butzbach
140150
120
45
140
H1
80 80
volumeter/PT-corrector
type EVC 24
Dimensions
058147.4
Pr
EC24
Flow direction from left to right
*
Flow direction from right to left*Standard installation
TERZ meter
(flange-design)
display
Pr
display
Ø 6 x 1
Ø 6 x 1
pipe no. 1
pipe no. 2
DN H1
25 190
40 190
50 225
80 260
100 265
150 295
200 325
250 370
300 385
400 375
500 395
