RMG EC 24 - Totalizers; Flow Rate; Pressure

OPERATION
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
Manual EC 24 · EN05 · 2015-02
22
Totalizers
Pointer position
V
Coding
Coordinate /
Line
A
Description of the coordinate Unit Special feature
S 1 Nm3 Main totalizer, volume at base conditions m3
S 2 m3 Main totalizer, volume at measurement conditions m3
S 3 VbD Disturbing quantity totalizer, volume at base conditions m3
S 4 VmD
Disturbing quantity totalizer, volume at measurement
conditions
m3
S 5 I/m3 Pulse scaling factor I/m3
S 6 I/m3 Meter factor I/m3
D 9 ... 22
Monthly data memory 1 ... 14
(Date, Vb, Vm, dVb, dVm, P, T)
Flow rate
Pointer position
V
·
Coding
Coordinate /
Line
B
Description of the coordinate Unit Special feature
D 1 N3H Flow rate at base conditions m3/h
D 2 m3/h Calculated flow rate at measurement conditions m3/h
D 3 F Frequency (measurement) Hz
S 4 Qm< Lower fault limit m3/h
S 5 Qm> Upper fault limit m3/h
D 6 Qmx
Maximum value of the flow rate at measurement
conditions
m3/h
S 7 qug Creeping limit m3/h
S 8 qmt Time limit for operation below Qm< s
Pressure
Pointer position
P
Coding
Coordinate /
Line
C
Description of the coordinate Unit Special feature
D 1 bar Measured value for pressure (absolute pressure) bara
S 2 p< Lower fault limit bara
S 3 p> Upper fault limit bara
S 4 pb Specified value, pressure at base conditions bara
C 5 p-def Default value, pressure bara
D 6 Dig Pressure, binary display
D 7 Dig Binary value at 0.5 V
D 8 Dig Binary value at 4.5 V
S 9 Umi Constant, pressure transmitter base calibration V
S 10 pmi Constant, pressure transmitter base calibration bara
S 11 p-S Constant, pressure transmitter base calibration
S 12 pA0 Correction value, pressure transmitter (factor)
S 13 pA1 Correction value, pressure transmitter (offset)
