OPERATION
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
Manual EC 24 · EN05 · 2015-02
26
0 1 2 3 4 5 6 7 8 9
EcMode2[7]
Tamper contact
mode
OFF
tamper contact closed
tamper contact open
EcMode2[6]
Spare
mode
EcMode2 (coordinate Z13)
EcMode2[5]
Device type-
mode
meter
meter + T
meter + p + T
corrector + T
corrector + p + T
EcMode2[4]
Spare
mode
EcMode2[3]
Spare
mode
EcMode2[2]
Protection
mode
fiscal metering
secondary metering
EcMode2[1]
GERG-TB
mode
0
15 20 25
EcMode2[0]
GERG-TN
mode
0.00°C
15.00°C 15.56°C 20.00°C
0 1 2 3 4 5 6 7 8 9
The connection of a tamper contact is only possible with the one- channel version via the sensor input 2.
