ANNEXES
...............................................................................................................................................................................................................
...............................................................................................................................................................................................................
Manual EC 24 · EN05 · 2015-02
35
Outputs
HF output
In the case of the explosion-protected (Ex) design, the device can only be connected to a certified
intrinsically safe circuit.
Connector: 3 (-) internally: X4,3
6 (+) internally: X4,4
Output: Open-drain transistor
T
Pulse
: 1 ms ± 10%
F
max
: 300 Hz
Ex Non-Ex
U
min
: 2.0 V 2.0 V
U
max
: 28 V 30 V
I
max
: 60 mA 400 mA
External inductance 1 H
External capacitance 25 μF
LF output
In the case of the explosion-protected (Ex) design, the device can only be connected to a certified
intrinsically safe circuit. (For Ex connected loads, see the approval certificate.)
Connector: 1 (-) internally: X4,1
4 (+) internally: X4,2
Output: Open-drain transistor
T
Pulse
: 125 ms ± 10% (F
max
: 4 Hz)
250 ms ± 10% (F
max
: 2 Hz)
Ex Non-Ex
U
min
: 2.0 V 2.0 V
U
max
: 28 V 30 V
I
max
: 60 mA 400 mA
External inductance 1 H
External capacitance 25 μF
