Rhein-Nad
el Automation GmbH
14
VT
-
BA
-SCU1000-
2000
-EN_
2019
/
27.06.2019 SJ
5.
Connections on th
e controller
5.1.
SCU1000
5.2.
SCU2000
Attention!
W
hen replacing the fuse be sure to use
the specified rating of
M6.3
A/250V
.
Too high a fuse rating m
ay destro
y the controller.
Power cable w
ith shockproof plug
X22
Status output
X21
Enabling input
F1
Access to fuses
F2
F1
Access to fuses
F2
Power switch
Power supply connecto
r
X0
Power switch
Connection for
vibratory feeder
X1
Connection for
vibratory feeder
X1
13
15
