7.2. Description of SCU1000 & SCU2000 parameters
Description of parameters in the parameters menu.
Feed rate setting in %.
Can be set from 0 to 100%.
Can also be changed in the status display (if PSP parameter at 0).
External enabling function.
1 = vibrating drive runs without external signal and stops when external signal is active.
0 = vibrating drive stops without external signal and runs when external signal is active.
Soft start time, run-up time from feeder start.
Can be set from 0 to 10s, default setting is 0.1s.
Soft stop time, run-down time from feeder stop.
Can be set from 0 to 10s, default setting is 0.1s.
Boost factor, can be set from 0.8 to 1.2. Only effective in full-wave mode (100/120Hz).
Default setting 1.0
Changing the boost factor is not necessary in normal operation. Such change is only required in
case of special vibrating drive systems.
Lower limit of feed rate.
Can be set from 0 to 35%.
Inhibiting feed rate change in the status display.
0 = enable (default setting)
1 = inhibit
Feed rate setting is only possible in parameter o.
Display of operating mode or vibrating frequency (only with vibrating drive connected):
1 = 50/60Hz (half wave)
2 = 100/120Hz (full wave)
The change of operating mode or vibrating frequency takes place only via coding in
the vibrating motor connector. See chapter 4.2.
Display of the controller software version.
Return to status display.
Attention
Setting of wrong parameters may result in electrical or mechanical damage to the controller or vibrating
motor.
Therefore, set a low feed rate on the controller before starting. Then watch proper operation while the out-
put is increased.
Attention!
Improper setting of the boost factor will overheat the connected magnets.
o. 75.0
Hi. 1
b. 1.0
0.2
. 0.2
PL. 35
P.s.p. 0
HA. 1
5.no.
End
