7. Operation of SCU1000 & SCU2000
LED display:
A short while after starting of the controller the status display comes up and the set feed rate is shown.
Other potential display readings:
External enabling signal missing or wrong parameter assignment.
The parameter b (Boost) has been changed from 1.0 to another value.
Supply voltage too low.
(This message appears for a few seconds when the device is switched on or off.)
Buttons:
Using the arrow buttons you can change setpoints and scroll through the menu.
Press the ENTER button to apply the values changed.
Changing the feed rate:
Upon pressing of the ENTER button the decimal point starts blinking on the status display and you can set the feed
rate using the arrow buttons. Press ENTER again to complete the entry. The decimal point stops blinking.
Opening the parameters menu:
Press both arrow buttons at the same time. The parameters menu will come up after one second. The display shows
the first parameter with its set value. Using the arrow buttons you can scroll through the list of parameters. For descrip-
tion of parameters see below.
Changing parameters:
Press the ENTER button to change a parameter. While the decimal points are blinking you can change the parameter
using the arrow buttons. Press ENTER again to complete the entry. The decimal points stop blinking.
Exiting the parameters menu:
Scroll through the parameters menu until the display shows End. Press ENTER to see the status display.
The status display will also appear if you press both arrow buttons at the same time for one second.
