If the power to the vehicle is not available, the awning can be safely retracted using the manual
override located on the idler (right) end of the case. (Picture 30.4)
This procedure cannot be used to extend the awning.
1. Remove the plug from the right end cap and save.
2. Insert a 3/8” socket drive extension and handle into the square drive hole inside the
endcap.
3. Turn the handle clockwise until the awning is retracted.
4. Replace the plug.
After closing the awning with the manual override, the lead rail may move out from the
case 1/4"-1/2”. This is normal and the awning is secure for travel until the power is
restored or repairs are completed. Do not attempt to force the lead rail in with the override,
serious damage can occur to the awning.
Picture 30.4
