5.
DISASSEMBLY
and
REASSEMBLY
5-1
PREPARATIONS
and
SUGGESTIONS
1)
When disassembling the engine, remember well the locations of individual parts
so
that they can be reas-
sembed correctly.
If
you are uncertain
of
identifying some parts, it
is
suggested that tags be attached
to
them.
2)
Have boxes ready
to
keep disassembed parts by group.
3)
To
prevent missing and misplacing, temporarily assemble each group of disassembed parts.
4)
Carefully handle disassembed parts, and clean them with washing oil.
5)
Use the correct tools
in
the correct way.
5-2
SPECIAL
TOOLS
For
your reference, the following shows special tools of Robin Engine for Disassembly, Measuring and Inspec-
tion Instruments.
Part
No.
2099500407
2309500107
2079500307
2309500207
2059500107
Tool
Flywheel Puller
(with
bolt)
Valve Spring
Retainer
Valve Guide
Puller
Use
For pulling
off
Flywheel
For mounting and
dismounting Valve
Spring Retainer
and Retainer
Lock
For pulling off
Valve guide
Applicalbe
Model
EY08
EY10, 13, 14
EY
15,18,
20
EY23, 25, 27,
EY33
EY35,40,44
EC05.07, 10
EC17,25.37
EY08
EY10,13, 14
EY 15, 18,20
EY23
EY25.27, 33
EY35,40,44
EY08
EY10
EY13,
14
Shape
-10-
