Robin FL-H7500 - Page 18

17
  
NO. Partname AssemblingInstructions
 
1
ENGINE
 〜CASE2,VOLUTE
〜BASE1,2
(1) FixtheENGINEtotheCASE2,VOLUTEwiththeknockpositionsunited.
(2) BecarefulnottoleavethehightensioncodeandwirebetweentheCASE2,VOLUTEand
ENGINE.
(3) InstalltheGASKET,MUFFLERontheCASE2,VOLUTEribwiththenumber(a)asshownin
thephotograph.
2
IMPELLER

SOCKETHEADBOLT
M6*30W,SW(6PCS)
Tighteningtorque80   ㎏ｆ･㎝
+20

0
BASE1,2

CASE2,VOLUTE

IMPELLER

SOCKETHEADBOLT
M6*40W,SW(4PCS)
Tighteningtorque80   ㎏ｆ･㎝

+20

0
AfterscrewingtheSOCKETHEADBOLTS
in numerical serial sequence (①−④
),
check if they are tightened with the
specifiedtighteningtorque.
①
②
⑥
③
④
⑤
Screwingsequence
ScrewtheSOCKETHEAD
BOLTSinnumericalserial
sequence(①−⑥).
①
②
③
④
⑤
OK

NG

(3)

(a)

