Robin FL-H7500 - III. DISASSEMBLY AND REASSEMBLY PROCEDURE; 1. EQUIPMENT DISASSEMBLY

Ⅲ．DISASSEMBLYANDREASSEMBLYPROCEDURE
1.EQUIPMENTDISASSEMBLY
Forfurtherdisassemblinginstructionsoneachpart,seethecorrespondingpages.
step
Partofremove
Procedure
Fastener
PCS
Notice
Specialtool
1)UnscrewtheDRAIN,BOLT
(5−1)andCAP,OIL(5−2)
M8×12 1
2)DraintheENGINEOIL.
3)ScrewtheDRAINBOLTand
CAP,OIL.
2 Fuel 1)Drainthefuel.
1)RemovetheCOVER,AIR
CLEANER.
KNOBBOLTM5
1
2)RemovetheAIRCLEANER
ELEMENT.
KeepcontaminantordustofftheAIR
CLEANERELEMENT.
3)RemovetheDUCT,AIR
CLEANER.
HOSECLAMP
1)RemovetheGUARD,OIL.
2)RemovetheSTARTER. M5×20mm 3
3)RemovetheCOVER,ENGINE 5X16mm 4
1)Removethefueltube. Thefuelwillspoutifthefueltubeis
removedwiththefueltankfilledwith
fuel.
2)RemovetheTANK,FUEL. M6X12mm 2
1)RemovetheWIRE.
2)RemovetheCONTOROLCABLE.
4X16mm 5
M5×25mm
1
2)RemovetheTHROTTLELEVER
2fromtheLEVER2ASSY.
M6×14mm
1
7 CASE,AIRCLEANER
P11
1)RemovetheCASE,AIRCLEANER.
M5×16mm 4
1)Removethe
PLATE,SEPARETOR.
BesuretopullthePLATE,SWPARATOR
byitsbody.
2)RemovethePLATE,CHECK
VALVE(withCHECKVALVE).
3)RemovetheCHECKVALVE(1).
DonotlettheCHECKVALVE(1)missing.
1)RemovetheSCREW
theDAMPER1side.
M5×40mm 1
2)RemovetheFRANGENUTthe
DAMPER2side.
M5 2
5X16mm 9
M5×65mm 2
M5 2
2)RemovetheELBOW.
3)RemovetheDAMPER2.
10 IMPELLER P13 1)RemovetheIMPELLER. M6X45mm 4
11 ENGINE P13 2)RemovetheENGINE. M6X30mm 6
6 LEVER(WIRE&CABLE)
P11
4 COVER,ENGINE
P10
5 TANK,FUEL
P10
Keepcontaminationordustoffthe
DRAINBOLTandCAP,OIL.
3 COVER,AIRCLEANER
P9
1 ENGINEOIL
Forfurtherinstructions
ontheengineoildraining,
seepage60.
1)RemovetheLEVER1and
LEVER2ASSY.
6-1 LEVER
P14
1)RemovetheCASE1,VOLUTE.
8 FRAME
P12
9 CASE1,VOLUTE
P12
BLEAHER(AIR
CLEANER)
P11
7-1
5-1
5-2
5
