Robin FL-H7500 - 2) Reassembly

50
6．RECOILSTARTER

TheRECOILSTARTERrarelymalfunctionsundernormaluse.Whenitfails, however,orneeds
greasing,disassembleandreassembleitaccordingtothefollowingprocedure.
Tools:Screwdriverandpliers

１）Disassembly
 （１）RemovetheRECOILSTARTERfrom
    theengine.
 （２）PullouttheSTARTERKNOB,press 
        theROTARYREELwithyourthumb
        asshowninFig.6-1whentheREEL 
        cut-outcomestotheSTARTERROPE
        OUTLET,andpulltheSTARTERROPE
        totheinsideoftheRECOILSTARTER
        withascrewdriver.Usingthe
        cut-out,rewindtheREELtothe
        directionofthearrowuntilit
        stopsbycontrollingtherotation
        oftheREELwithyourthumb.
 （３）RemovethepartsasshowninFig.6-2.
        RemovetheREELslowlybyturningitbackandforthgentlyinawaythat
        SPIRALSPRINGwillnotcomeawayfromtheREEL.
        (Besuretowearapieceofprotectiveglassesduringdisassemblingtoprotect 
        againstadangercausedbypossiblespiralspringscomingaway.Ifthespiralringfliesout, 
      fititcorrectlyintothegrooveaccordingtotheproceduresasshowninFig.6-6.)
        UntietheSTARTERROPEknotattheREELendandtakeitawaytocompletethe
        disassembly.
























Fig.6-2
SETSCREW
COLLAR
SWINGARM
SPRING
STARTERROPE
REEL
SPIRALSPRING
STARTERSHAFT
STARTERKNOB
Fig.6-1
Fig.6-2
