Ⅸ．CHECK,DRAINAGEANDFEEDINGOFENGINEOIL
Recommendedoil:RobingenuineoilorSAE10W-30oilofAPItypeSFgradeorbetter(4strokemotoroilfor
automobiles)
Oilcapacity:Approximately0.22L(220ml)
1.CheckingandRefillingEngineOil
① Followtheprocedurebelowwhentheengine
oiliscoldi.e.theblowerhasnotbeen
running.
• Inspection：Settheblowerdownonalevel
surfaceandremovetheoilcap.Verify
thattheoilleveliswithintheupper
andlowerlimitmarksontheoillevel
gauge.Iftheoilisnotuptothe
100mLlevel,fillupwithnewoil.
• AddingOil：Settheblowerdownonalevel
surfaceandremovetheoilcap.Fill
theoiluptotheupperlimitoftheoil
levelgauge.
2.OilChangeProcedure
① Settheblowerdownonalevelsurface.
② Placeawasteoilcontainerunderthedrainagehole(1)to
catchtheoilasitdrainsout.Thecontainershouldhavea
capacityofatleast220mltobeabletocatchalloftheoil. 
③ Loosentheoildrainbolt(2)tolettheoildrainout.Be
carefulnottoallowoiltogetonthefueltankorotherparts.
④ Removetheoilcap.(Removingtheoilcapallowstheoilto
draineasily.) 
⑤ Astheleveloftheoilbeingdraineddecreases,tiltthe
bloweroverontothesidewiththedrainsothattheoilwill
completelydrainout.
⑥ Aftertheoilhascompletelydrainedout,tightentheoildrain
boltsecurely.Iftheboltisnottightlyfastened,thismay
resultinanoilleak.
⑦ Addingoilduringtheoilchangeprocedureisperformedin
thesamemannerastheseparatelyexplainedprocedurefor
addingoilwheneverthelevelisinsufficient.Alwaysaddoil
byfillingfromtheopeningundertheoilcap.(Specifiedoil
level:Approximately220mL)
⑧ Afterfillingwithoil,tightentheoilcapsecurelytoprevent
oilleaks.
Oillevel
gauge
Upperlimit
Lowerlimit
Remain100mL

Drain
Oildrainbolt
Packing
(aluminumwasher）
Oilcap
